| Model NO. | C10TX Pro |
| Certification | CE, FDA, EEC, MSDS, ISO13485 |
| Product Name | Handheld Ultrasound |
| Probe | Wireless Dual Head Convex+Linear+Cardiac Probe |
| Elements | Dual 92 |
| Frequency | 3.2/5Mhz, 7.5/10Mhz, 2.5/5Mhz |
| Host Connection | Android/IOS/Windows Tablet, Smart Phone, PC via WiFi & USB |
| Battery Performance | 4 Hours (Working Time), 72 Hours (Stand By) |
HANDHELD ULTRASOUND
Experience the future of medical diagnostics with our state-of-the-art handheld ultrasound system. This ultra-portable, pocket-sized ultrasound device empowers healthcare professionals to make faster, more accurate clinical decisions right at the point-of-care. By connecting wirelessly to your smartphone or tablet, it delivers crystal-clear, real-time imaging without the need for bulky equipment.
Weighs only a few ounces and fits easily into a lab coat pocket, enabling healthcare providers to carry diagnostic imaging capability anywhere.
Enables immediate imaging at the bedside or in emergency situations, reducing wait times and accelerating clinical decisions.
Features a simplified, touch-based mobile app interface that reduces learning curve and training time significantly.
| Probe Presets | Abdomen, GYN, OB, Cardiac, Urology, Kidney, Lung, Thyroid, Small Parts, Pediatrics, Vascular, Carotid, Breast, MSK, Nerve, Aesthetics. |
| Software Adjustable | Gain, Depth, Enhancement, Dynamic Range, Frequency, FocusPos, PRF, WF, Mode, 8TGC, Biopsy, Annote. |
| Measurement Modes | B: Length, Area, Angle, Distance, GA, EFW; B+M: Heart Rate, Time, Distance, LVID; B+PW: Velocity, S/D. |
| Display Modes | B, B+B, B/M, Color, PW, PDI, B+Color+PW |
| WiFi Type | Built-In WiFi, 802.11G/20MHz/5G/450Mbps |
| Waterproof Grade | IP68 |
| Charging | Wireless Charger |
Extended rechargeable battery life supports hours of continuous scanning without interruption.
Immediate availability accelerates emergency diagnoses and improves patient satisfaction.
Engineered to withstand demanding clinical use, including frequent handling and cleaning protocols.
